L956F
Category： Wheel loader
Rated bucket capacity: 3.0 m3 (2.7～4.5) Rated carrying-capacity (kg): 5000 Maximum traction force (kN): 165 kN Tipping load: ≥110 kN Maximum breakout force: ≥175 kN Forward I (km/h): 0~13 km/h Forward II (km/h): 0~38 km/h Reverse I (km/h): 0~17 km/h Overall length (mm): 8260 Engine model/Drive Motor Model: WD10G220E23
leave a message now >Specifications
| 1.Parameter | ||||
| Rated bucket capacity | 1.8 m3 | Minimum steering radius (outside of rear wheel) | 5381mm | |
| Rated carrying-capacity (kg) | 3000 | Transverse passing radius (outside of bucket) | 6020 mm | |
| Maximum traction force (kN) | ≥105 kN | altitude | - | |
| Tipping load | ≥66 kN | ambient temperature | - | |
| Maximum breakout force | ≥96 kN | wading depth | - | |
| Forward I | 0～13 km/h | Forward Ⅱ(km/h) | 0～38 km/h | |
| Forward Ⅲ(km/h) | - | Forward Ⅳ(km/h) | - | |
| Reverse I (km/h) | 0～17 km/h | Reverse II | - | |
| Reverse III | - | Reverse IV | - | |
| 2.Dimension | ||||
| Overall length (mm) | 7230 | Overall width (mm) | 2520 | |
| Outside width of wheel | 2310 mm | Wheel track | - | |
| Overall height (mm) | 3170 | wheelbase（mm） | 2850 | |
| Dumping angle | -45° | Maximum dumping height | 2950 mm | |
| Number of axles | 2 | Corresponding dump reach | 1050 mm | |
| Maximum lifting height of fork horizontal section (mm) | - | Total mass (kg) | 10400 | |
| Minimum ground clearance | 370 mm | Axis pin at maximum lift height | 3790 mm | |
| Wheelbase (front/rear) (mm) | - | - | - | |
| 3.Engine | ||||
| Engine model/Drive Motor Model | WP6G125E22 | Number of cylinders | 6 | |
| Engine type | In-line、 water-cooled、 dry sleeve、 direct injection | Bore/stroke | 105/130 mm | |
| Engine power (KW) | 92 | Minimum fuel consumption | 215 g/kw.h | |
| Rated engine speed | 2200 r/min | Maximum torque (N.m)/rotation speed (r/min) | 550 N.m | |
| Displacement (ml) | 6750 | Emission standard | GB 20891-2007 | |
| 4.Transmission system | ||||
| Type of torque converter | Single-stage four-element twin turbine torque converter | Torque ratio | 4.56 | |
| Oil cooling mode | Circulating water cooling | Oil pressure of torque converter inlet | 0.5～0.6 MPa | |
| Oil pressure of torque converter outlet | 0.21～0.26 MPa | Transmission type | Planetary power shift | |
| Shifting gears | forward 2 reverse 1 | Gear ratio of forward I | 2.547 | |
| Gear ratio of forward Ⅱ | 0.683 | Gear ratio of forward Ⅲ | - | |
| Gear ratio of forward Ⅳ | - | Gear ratio of reverse I | 1.864 | |
| Gear ratio of reverse II | - | Gear ratio of reverse III | - | |
| Gear ratio of reverse IV | - | Model of variable-speed pump | LG03-BSB | |
| Working pressure of shifting | 1.1～1.5 MPa | Main drive type | First reduction of spiral bevel gear | |
| Main drive reduction ratio | 6.167 | Wheel reduction type | One-stage planetary reduction | |
| Wheel reduction ratio | 3.12 | Drive type | CHANGCHAI four-wheel drive | |
| Tyre size | 17.5-25 | Front tyre pressure | 0.333～0.353 MPa | |
| Rear tyre pressure | 0.275～0.294 MPa | Type of foot brake | Air-over-oil caliper disc brake | |
| Brake pressure (MPa) | 0.784 MPa | Parking brake type | Electric air-controlled caliper disc brake | |
| 5.Steering system | ||||
| Type of steering system | Load-sensing full hydraulic articulated steering | Model of priority valve | VLE-150 | |
| Steering pump model | CBGj2063A | Steering cylinder - bore x rod diameter x stroke | HSGL-80×45×327 mm | |
| Steering gear model | BZZ6-500A | Steering angle (°) | 37° | |
| Working pressure of steering system | 12 MPa | - | - | |
| 6.Working equipment | ||||
| Type of working device | Hydraulic pilot control | Boom cylinder - bore × rod diameter × stroke | HSGF-125×70×771 mm | |
| Turning bucket cylinder - bore x rod diameter x stroke | HSGF-140×80×502 mm | Model of working pump | CBGj3100/1010-XF | |
| Displacement of working pump (ml/r) | - | Model of multi-way valve | D32-16 | |
| Model of pilot valve | DXS-00 | Working pressure of working device hydraulic system | 16 MPa | |
| Bucket lift time (full load) | ≤5.3 s | Bucket fall time (no load) | ≤2.9 s | |
| Bucket dumping time (no load) | ≤1.0 s | Time sum of three items | ≤9.2 s | |
| 7. Oil filling amount | ||||
| Diesel filling capacity of fuel tank | 140 L | Oil filling capacity of axles (main drive and wheel reducer) | 2×18 L | |
| Oil tank filling capacity | 128L | Engine oil filling capacity | 18 L | |
| Transmission oil filling capacity | 44 L | Refueling of antifreeze coolant | - | |
| Oil filling capacity of braking system | 4 L | - | - | |
Benefits & Features
-
Enhanced Bucket Capacity: The product offers a versatile bucket capacity ranging from 2.7 to 4.5 cubic meters, standard at 3.0 cubic meters, allowing for increased flexibility and productivity in various loading tasks.
-
Increased Payload Capability: With a rated carrying capacity of 5000 kilograms, the product is designed to handle heavy payloads efficiently.
-
Powerful Traction and Breakout Forces: Equipped with a maximum traction force of 165 kN and a tipping load exceeding 110 kN, along with a maximum breakout force exceeding 175 kN, the product ensures robust performance in challenging conditions.
-
Speed and Versatility: The product provides a range of speed options, with Forward I at 0 to 13 km/h and Forward II at 0 to 38 km/h, along with a Reverse I speed of 0 to 17 km/h, catering to diverse operational requirements.
-
Optimized Dimensions: The overall length of 8260 millimeters and overall width of 3024 millimeters, combined with a compact wheelbase of 3200 millimeters, contribute to the product's maneuverability and stability.
-
Advanced Engine Technology: Powered by a WD10G220E23 engine, featuring an inline, water-cooled, direct injection, and dry sleeve design with a displacement of 9726 milliliters, the product delivers 162 kW of power and complies with GB 20891-2007 emission standards.
-
Efficient Transmission System: The product features a planetary power shift transmission with a single-stage four-element twin-turbine torque converter, offering a torque ratio of 4.2 and oil cooling mode for reliable performance.
-
Robust Hydraulic System: The hydraulic system, with a working pressure of 18.5 MPa, utilizes a hydraulic pilot control for precise and responsive operation of the working equipment.
-
Ample Fuel and Fluid Storage: A generous fuel tank capacity of 260 liters and hydraulic oil tank capacity of 240 liters, along with other essential fluid capacities, ensures extended operation times.
-
Safety and Braking System: The product is equipped with an air-over-oil caliper disc brake and an electric air-controlled internal expansion shoe parking brake, ensuring effective deceleration and safety.
